RLB600
Extra deep tread on/off highway severe service drive-position tire
RLB600
Extra deep tread on/off highway severe service drive-position tire
The Double Coin RLB600 is designed with open shoulders and extra deep tread for ultimate traction. This rugged on/off highway drive-position tire is built for severe environments and will provide superior grip in all types of conditions and applications.
RLB600 Highlights
-
Extra deep with over an inch of tread for long life even in challenging mixed service applications
-
Center sipes in the tread blocks cut through water and debris, providing excellent traction and stability
-
Open shoulder design for evacuation of mud and soft soil
Additional information
| DC Application | Mixed Service |
|---|---|
| DC Positions | Drive |
| Double Coin TBR Tire Size | 11R22.5, 11R24.5 |
RLB600 Specifications
Product Code
Size
Ply Rating
Load Range
Load Index
Speed Symbol
Overall Diameter (inch)
Section Width (inch)
Tread Depth (32nds)
RIM
Single Max Load/Pressure
Dual Max Load/Pressure
Static Load Radius
Revs per Mile
Weight (lb)
Tire Type
1133491256
11R22.5
16
H
148/145
G
43.0
11.1
33
8.25
6940lb/123psi
6390lb/123psi
20.6
478
139
TL
1133491456
11R24.5
16
H
149/146
G
44.0
11.1
33
8.25
7160lb/120psi
6610lb/120psi
21.6
455
152
TL
