AGROLOX

Radial Tractor Tire (R1W)

AGROLOX

Radial Tractor Tire (R1W)

  • Increased traction with an updated variable-angled tread pattern for both soil and road usage
  • Comfortable ride both in the field and on the road
  • Extra protection in the tread area against fatigue and cracking thanks to the increased tooth block
  • Consisting durable blocks
  • Increased productivity with special pattern design
  • High resistance against punctures and tears thanks to 3-layer bar structure

Flexible sidewall structure
Double-angle tread structure
High speed and traction
Durable bar structure

Compatible Vehicle Models:

2WD Tractor, 4WD Tractor, Combined Harvester, Sprayer

Compare

AGROLOX Highlights



  • Increased traction with an updated variable-angled tread pattern for both soil and road usage
  • Comfortable ride both in the field and on the road
  • Extra protection in the tread area against fatigue and cracking thanks to the increased tooth block
  • Consisting durable blocks
  • Increased productivity with special pattern design
  • High resistance against punctures and tears thanks to 3-layer bar structure

AGROLOX Specifications

Product Code
Tire Size & Ply Rating
TT/TL
Inflated Unloaded Dimension - Section Width (inch)
Inflated Unloaded Dimension - Overall Diameter (inch)
Load Index
Speed Symbol
Tread Depth (32nds)
TRA Code
Load & Pressure - Tire Load Capacity (lbs)
Load & Pressure - Tire Pressure At Max. Load (Psi)
Dynamic Rolling Circumference (inch)
Static Loaded Radius (inch)
70 Series
1947024381
380/70 R24
TL
15
46.9
125/128
D/A8
53
R-1W
3640
23
140
21.1
70 Series
1947024421
420/70 R24
TL
16.5
49.1
130/133
D/A8
55
R-1W
4180
23
146.5
22
70 Series
1947028381
380/70 R28
TL
15
50.9
127/130
D/A8
53
R-1W
3860
23
152.7
23.1
70 Series
1947028421
420/70 R28
TL
16.5
53.2
133/136
D/A8
55
R-1W
4640
23
159.2
24.1
70 Series
1947028481
480/70 R28
TL
18.9
56.1
140/143
D/A8
59
R-1W
5520
23
167.4
25.2
70 Series
1947034481
480/70 R34
TL
18.9
62.2
143/146
D/A8
57
R-1W
6000
23
186.6
28.3
70 Series
1947038481
480/70 R38
TL
18.9
66.3
145/148
D/A8
57
R-1W
6400
23
199.5
30.4
70 Series
1947034521
520/70 R34
TL
20.3
64.6
148/151
D/A8
58
R-1W
6950
23
193.2
29.2
70 Series
1947038521
520/70 R38
TL
20.3
68.9
150
D
59
R-1W
7400
23
205.6
30.2
70 Series
1947038581
580/70 R38
TL
22.7
71.9
155
D
64
R-1W
8550
23
214.2
32.4
60 Series
1946032900
900/60 R32
TL
35.6
73.6
182/185
D/A8
69
R-1W
18700
58
218.2
32.6
