IM105
Fuel efficient container chassis radial tire
IM105
Fuel efficient container chassis radial tire
The Double Coin IM105 container chassis tire is an EPA SmartWay®-verified, low rolling resistance radial tire built for intermodal applications. It is also engineered with additional ozone protection that lasts up to 12 years.
IM105 Highlights
-
EPA SmartWay®-verified and CARB compliant for superior fuel savings and reduced emissions
-
Engineered with Double Coin’s superior manufacturing quality standards to deliver consistent quality and durable casings
-
Advanced compounds with added ozone resistance for longer service life
Información adicional
| DC Application | Intermodal |
|---|---|
| DC Positions | Trailer |
| DC Feature | Fuel Efficient (SmartWay®) |
| Double Coin TBR Tire Size | 11R22.5, 295/75R22.5 |
IM105 Specifications
Product Code
Size
Ply Rating
Load Range
Load Index
Speed Symbol
Overall Diameter (inch)
Section Width (inch)
Tread Depth (32nds)
RIM
Single Max Load/Pressure
Dual Max Load/Pressure
Static Load Radius
Revs per Mile
Weight (lb)
Tire Type
1133831255
11R22.5
14PR (LRG)
G
144/142
M
41.1
11.2
12
8.25
6175lb/105psi
5840lb/105psi
19.3
505
110
TL
1133839255
295/75R22.5
14PR (LRG)
G
144/141
M
40.0
11.7
12
8.25
6175lb/110psi
5675lb/110psi
18.7
520
105
TL
